Orifice embedded data gateway
Orifice embedded data gateway
AZ270 series orifice embedded data gateway is a highly integrated digital acquisition device, especially suitable for installation scenarios where there are no installation conditions on the ground and the installation of the lower part of the ground is required. The product integrates power supply, collection and transmission, can be quickly arranged and used, and supports fixed installation in water level holes and inclination nozzles; For low-frequency acquisition, the unit comes with its own battery to support long-term use.
AAZ270 series gateway supports power supply and measurement signal acquisition and transmission of various current transmitters, especially suitable for connecting submersible current level transmitters to measure groundwater level; At the same time, it supports the acquisition and transmission of RS485 interface sensor measurement signals such as modular deep horizontal displacement and layered displacement measurement.
AIP68 protection level, suitable for outdoor work environment exposure.
Basic functions
- Dimensions: Φ 63 x 120 mm
- Power supply, collection and transmission are integrated
- 1 AD interface for connecting 4 to 20mA current transmitters
- 1 RS485 interface, with power supply output, support to connect RS485 interface sensors
- Built-in antenna, NB/4G and other wireless communication methods are optional
- Ultra-low power consumption, fully built-in battery, continuous use twice a day for more than one year
- Support direct power supply from solar panels
- IP68
